1. Extruder 1set
Material: PP Virgin
Screw diameter: Φ90MM
Screw L/D:1:33
Screw material: 38GrMoAl
Screw max. rotation: 120r/min
Barrel heating use cast alumunium heating band
Barrel total heating power and zones: 35KW
Surface hardened Gearbox brand
Die use inlay stainless steel heating pipe, Solid relay control the
heating
Die length: 1000MM
Film thickness: 0.07MM-0.35MM
die total heating power and zones: 12KW
Main motor: Siemens(China) AC motor
Motor power:30KW
Screen change method: auto-belt change screen
2.Cooling water tank 1 set
Material: Stainless steel
3. Lifting Film broken pulling device: 1 set
Squeezing water rubber roller: 1 set
Lifting device 1set motor power: 3KW
Squeezing water device: 1 set
Water suction device fan power: 3kw
Film broken device 1set
Pulling roller 2sets
Roller outer diameter: Φ185MM
Motor power: 5.5KW
Max. Speed : 55 m/min
For direct return of narrow edge trims of non-stretched film into
the extruder, consisting of a
shredding mill with blower, piping and airseparator (cyclone).
Shredding Mill Motor 2.2 kW
Blower Motor 2.2 kW
4. Stretching plate: 1set
Drying plate length: 3500MM
Drying plate width: 850MM
Drying plate thickness: 16mm
Drying plate surface treatment
Heating power: 12KW
Drying plate equip with heat preservation upper cover
5. 7-roller stretching machine : 1 set
Steel roller dimension: Φ315x850mm
Stretching 5-roller motor power: 15KW
Setting 2-roller motor power: 4KW
Max. Speed 280 m/min
6. Fiber system 1set
Motor power:5.5Kw
7. Waste yarn collection system: 1 set
Moto wer 7.5KW
8. Winding machine: Spindle.
9. Electrical control system: 1set
