    4 Strand PET Plastic Rope Making Machine For High Strength Twisted Rope

    Rope Making Machine For High Strength 4 Strand Twist PET Rope


    Product Description:

    1. Extruder: 1 set

    (1) Screw dia.: 85mm; Rotation speed: 0~80rpm,

    (2) L:D: 30:1; The screw is special design for PET recylce material.

    (3) Pressure feedback system can adjust the screw speed automatically.

    (4) Melt filter: Melt filter changer with candles

    (5) Spinneret device: 1 set

    (6) Metering pump: 1 set

    (7) Color doserm: 1 set

    (8) Magnet device: 1 set


    2. Quenching Tank:1 set

    (1) The tank is made by Stainless Steel 304.

    (2) The horizontal pushing structure is conveniently to disassembly the spinneret.


    3. First Seven roller Stretching unit: 1 set

    (1) Seven pieces variable diameter roller with hard chrome plating.

    (2) Built-out oil lubrication system makes gears run steady.


    4. Hot water Tank:1 set

    (1) Heating power: 70KW; Electrical heating, copper heating pipe

    (2) Equip two pressing roller .


    5. Second seven rollers stretching unit

    (1) Seven pieces variable diameter roller with hard chrome plating.

    (2) Built-in oil lubrication system which makes the gears run steady.


    6. Spindle winder

    (1) Tapered winder

    (2) Winding bobbin as per clinet's reqeust.

    (3) Tesnion control by inverter.


    Parameter:

    Screw diameterΦ90mm
    Raw materialPETFilament size0.35mm
    Capacity100Kg/HFilament shaperound
    Screw L:D30:1Stretching unit2 sets
    Screw material38CrMoALAWinder33 spindles
    Max linear speed120m/minInstillation power130Kw
    Nozzle holes400 holesOverall size28×2.6×2.6m

    Pictures:
